LGM-Series, Mechanical Lock-Grip Pullers
The LGM-Series, Mechanical Lock-Grip Pullers are the simplest, safest and most cost effective way to remove shaft-mounted parts.
- Puller Capacity: 3 – 13 ton
- Maximum Reach: 102 – 215 mm
- Maximum Spread: 132 – 300 mm
- Puller Power Source: Mechanical
LGM-Series, Lock Grip Pullers are an ideal solution for pulling small to medium-size wheels, sprockets, bearings and other similar shaft-mounted parts. The puller’s self-centering closing system allows all jaws to move simultaneously, making it easy for a single operator to mount the puller and to perform the application.
Turning the puller handle locks the jaws onto the application, allowing the desired object to be pulled free when the spindle is turned.
AT A GLANCE
- Quickly and easily mount on a wide range of applications
- Lock-on jaws offer a secure grip for safe and easy operation
- Synchronous jaw movement enables entire pulling job to be performed by a single operator
- Available in 2 and 3-ja configurations
BENEFITS
- Convenient adjustment handle simplifies positioning of jaws on application and increases speed of operation.
- Locking mechanism helps prevent puller jaws from slipping off application during process.
- Greater spreading width on top portion of jaws enables use on thicker objects.
- Synchronous jaw movement increases ease of use, allowing one operator to mount the tool and perform the pulling application.
- Point protector helps prevent damage to spindle when pulling against a flat surface.
Point Protector
LGM-Series Pullers MUST be used with a point protector if the shaft end does not contain a drilled center hole.
One point protector is included with every puller.
